DIY leg mounted pedalboard

Post by Andre Dardeau »

Two camera mount clips, a couple 3/8” bolts, a Pedaltrain nano+ that up until now was an awkward size. I realized it sits right over my volume pedal and I can insert my volume pedals with two short right angle cables between the reverb and the eq. I feel pretty smart for this one.


Top
User avatar
Jim Fogarty
Posts: 1577
Joined: 14 Dec 1999 1:01 am
Location: Phila, Pa, USA
State/Province: -
Country: United States

Post by Jim Fogarty »

Good thinking Andre! Can you show a closer pic of how it mounts, including the underneath? I have a spare Nano+......

Thanks!
Top
David Becker
Posts: 277
Joined: 15 Nov 2016 7:50 am
Location: California, USA
State/Province: California
Country: United States

Post by David Becker »

I second Jim's question. I think I've figured it out, but I'd like to see it to be sure. Very clever, however it is you did it!

Thanks.
Top
User avatar
Larry Dering
Posts: 6075
Joined: 17 May 2013 11:20 am
Location: Missouri, USA
State/Province: Missouri
Country: United States

Post by Larry Dering »

I see you used 2 of my favorite leg clamps. Those camera clamps are the bomb for mounting things. An underside shot would be nice.
Top
User avatar
Karen Sarkisian
Posts: 1907
Joined: 29 Mar 2009 7:03 pm
Location: Boston, MA, USA
State/Province: -
Country: United States

Post by Karen Sarkisian »

love this! saves from having to bring a fold up stool to the gig.
Emmons
Top
User avatar
Jon Jaffe
Posts: 1161
Joined: 15 Nov 2004 1:01 am
Location: Austin, Texas
State/Province: Texas
Country: United States

Post by Jon Jaffe »

https://www.amazon.com/gp/product/B07PH ... E2K6&psc=1


Top
User avatar
Karen Sarkisian
Posts: 1907
Joined: 29 Mar 2009 7:03 pm
Location: Boston, MA, USA
State/Province: -
Country: United States

Post by Karen Sarkisian »

and how does the pedalboard attach?
Emmons
Top
User avatar
Jon Jaffe
Posts: 1161
Joined: 15 Nov 2004 1:01 am
Location: Austin, Texas
State/Province: Texas
Country: United States

Post by Jon Jaffe »

Through 1/4 and 3/8 machine threads. The same thread size that goes with camera and tripods. You can get them at HD or Lowes. Also you don't have to use a pedal board.


This a floating shelve from Amazon. Aluminum and easy to drill holes in. The Amazon link was too large. Search: Danpoo Metal Wall Shelf
