Post new topic Crawford Cluster Adjustments on Left Knee
Reply to topic
Author Topic:  Crawford Cluster Adjustments on Left Knee
Jeff Rady


From:
Colorado, USA
Post  Posted 13 Jan 2019 3:27 pm
Reply with quote

Hi All,

I recently bought a new E9 steel with a Crawford Cluster on the left knee, basically two inner knee levers, a vertical knee lever and of course the standard E lower and raise levers. How do you adjust the inner and outer knee levers for optimal use and any technique tips for not catching two levers at once? Any advice would be great! Thanks! JR
_________________
Williams Guitar Purveyor, Owner of www.radyguide.com
View user's profile Send private message Send e-mail Visit poster's website
John McClung


From:
Olympia WA, USA
Post  Posted 13 Jan 2019 4:03 pm
Reply with quote

This comes from Winnie Winston's great book, Pedal Steel Guitar: A Manual of Style, page 43:

Jimmie and later some others used LKL-Rear and LKR-Front as the "main" levers (for Crawford, LKL-Rear was E>F; LKR-Front was NOT E>Eb, but string 2 D>C#, and string 6 G#>F#).

So he'd push his knee forward to grab the staggered lever LKL-Front, and pull back to grab LKR-Rear.

Mickey Adams and I both use just 1 staggered LKL-Front, using that as a secondary lever. If I had 2 on LKR, I'd pull back the way Crawford did.

Buck Reid pulls back for both of his dual staggered levers, and they're spaced very close to the main levers in front of them.

Other players do the opposite, it just works better or feels right that way. So all this is a highly personal choice, one of the things I like best about pedal steel: near infinite variety in tunings, & pedal and lever setups.

Of course, that does create confusion and bewilderment in many beginners, which is way so many players just stick with a pretty stock setup.

Hope this helps, Jeff!
_________________
E9 INSTRUCTION
Mullen pre-RP D-12 9+10 / Zumsteel S12 7+6 / Li'l Izzy / Webb amp / Stereo Steel combo amp-preamp / JBL, BW & Telonics speakers in Telonics cabinets / Hilton and Telonics volume pedals / BJS bars / George L strings & cables / StealSeat.com pack-a-seat / Macintosh computers / This Space for Hire / Burma Shave
View user's profile Send private message Send e-mail Visit poster's website
Jeff Rady


From:
Colorado, USA
Post  Posted 14 Jan 2019 9:34 am
Reply with quote

Hi John,

Thanks for the advice. My rear LKL raises string 1 a half step and lowers 7 a whole step. My rear LKR lowers G#'s to G on 3 and 6. The only way I can get it to engage without engage my main LKR lower e's is to get on my the ball of my foot, which seems nuts, but maybe that's normal.

What does your Cluster do?

Your LKL front which is normally and E raise, does something else and then you lower with your rear staggered?

Thanks,

Jeff
_________________
Williams Guitar Purveyor, Owner of www.radyguide.com
View user's profile Send private message Send e-mail Visit poster's website
John McClung


From:
Olympia WA, USA
Post  Posted 15 Jan 2019 5:57 pm
Reply with quote

Here's my current extended E9 copedent, Jeff.

A staggered lever on the LKR is probably the hardest of all to use. Note my LKForward, which is a bear to use.

In my next copedent, I'm rearranging changes a bit, trying to stick with "just" 6 levers and get as much as I can working as well as possible. It's a tricky balancing act.
