Post new topic Fender amp for steel
Reply to topic
Author Topic:  Fender amp for steel
John Boyte


From:
Lake Providence, Louisiana, USA
Post  Posted 12 May 2019 5:45 am
Reply with quote

Hello all! I now officially have my Stage One Zum Encore on order. I have a '69 Fender Super Reverb that the cab is no good. That's ok because I don't want the weight of a 4-10 cab anyway. I am going to have it completely reworked electronically with both channels through reverb and have the Diaz mod to be able to turn vibrato off and gain a little more wattage. I will be using it for guitar but was thinking would it be advisable to have one channel voiced for PSG or would normal voicing be OK? Of course, I know PSG amps are usually higher wattage and this amp would maybe get 45 watts with mod. I don't usually play where a lot of volume is required. I have a Vintage Sound Deluxe Reverb that I guess could be used in parallel with this amp if volume ever was an issue. Also, since I am getting a new cab and have many speaker options available, what would you recommend that would work well for PSG and guitar? Thanks in advance for your advice!
View user's profile Send private message Send e-mail
J Fletcher


From:
London,Ont,Canada
Post  Posted 12 May 2019 1:33 pm
Reply with quote

Hi John
Super Rev could be excellent for steel. You will need a 2 ohm speaker load to get the most power , unless you change the output transformer. Jerry
View user's profile Send private message Send e-mail
John Boyte


From:
Lake Providence, Louisiana, USA
Post  Posted 12 May 2019 1:40 pm
Reply with quote

Thx Jerry. They will change the output transformer. Like I said, not going back with 4-10s due to weight. Do you have a preference for speaker size or number since will be for steel or guitar?
View user's profile Send private message Send e-mail
Derrick Unger


From:
Newark Ohio, USA
Post  Posted 12 May 2019 2:40 pm     speaker
Reply with quote

I would say your field is wide open...IMHO I think I would try a light-weight 15".
_________________
Music is good for the soul..playing it is even better! Gretsch6strLapSteel*PeaveyNashville400*HudsonSD-10*DigitechRP360*FenderChampion100*PeaveyKB300*Goodrich120*Behringerx1204*BehringerMini4*Mullen S10"Discovery"*Peavey Vegas400*Princeton112plus*SuperChampX2*SidekickReverb65*Rumble100*MarshallMG50DFX*Nashville112
View user's profile Send private message Send e-mail
Derrick Unger


From:
Newark Ohio, USA
Post  Posted 12 May 2019 2:41 pm     speaker
Reply with quote

I would say your field is wide open...IMHO I think I would try a light-weight 15".
_________________
Music is good for the soul..playing it is even better! Gretsch6strLapSteel*PeaveyNashville400*HudsonSD-10*DigitechRP360*FenderChampion100*PeaveyKB300*Goodrich120*Behringerx1204*BehringerMini4*Mullen S10"Discovery"*Peavey Vegas400*Princeton112plus*SuperChampX2*SidekickReverb65*Rumble100*MarshallMG50DFX*Nashville112
View user's profile Send private message Send e-mail
J Fletcher


From:
London,Ont,Canada
Post  Posted 12 May 2019 3:18 pm
Reply with quote

Well I don't gig much with pedal steel , and when I do , I play play guitar too so my amp has to work with my telecaster as well as my Emmons. A Celestion Vintage 30 works for me , but I would be in a minority with that speaker choice.
There are some 12 and 15's designed for steel guitar that would probably do a nice job for you , with neo magnets so the weight is considerably less than ceramic magnets.
Emminence makes a few models for steel.
Jerry
View user's profile Send private message Send e-mail
David Nugent


From:
Gum Spring, Va.
Post  Posted 13 May 2019 3:42 am
Reply with quote

Since you are having a new cab built and modifying the amp to feature both steel and six string designated channels, why not a 2x12" cab with the speakers separate as well, (one voiced specifically for steel and the other more standard guitar friendly)?
View user's profile Send private message
John Boyte


From:
Lake Providence, Louisiana, USA
Post  Posted 13 May 2019 4:52 pm
Reply with quote

If I understand you what you are saying, there will be the 2 pre-amps but through 1 power amp on the super. I think you were meaning speakers independent of each other?
View user's profile Send private message Send e-mail
Steve Schmidt


From:
Ramsey, MN, USA
Post  Posted 13 May 2019 7:39 pm
Reply with quote

The super reverb is an excellent amp for steel. That is my go to amp these days. I have a single TT12 in mine. That is such an efficient speaker you won't really notice a significant loss in volume. You could always replace the OT if your concerned about the impedance mismatch. It's a great solution.
View user's profile Send private message Send e-mail
Edward Rhea


From:
Medford Oklahoma, USA
Post  Posted 14 May 2019 4:04 am
Reply with quote

I love my Fender amps, for steel guitar. I don’t have a Super Reverb, but have played through my father in law’s, and zero complaints from me. His is completely stock and just sings!


_________________
“TONESNOB”
View user's profile Send private message Send e-mail
Steve Spitz


From:
New Orleans, LA, USA
Post  Posted 14 May 2019 2:28 pm
Reply with quote

I wouldn’t mess with the amp, it’s collectible. The “ voiced for steel part “ might be a steel friendly 15” speaker with a new baffle board. You could spend alot on modding this amp .

I wouldn’t do anything non reversible . That’s why the baffle board swap might work. I’d save the money and buy a used steel amp, and not destroy your super reverb.
View user's profile Send private message Send e-mail
David Nugent


From:
Gum Spring, Va.
Post  Posted 14 May 2019 4:37 pm
Reply with quote

John..Yes, exactly.
View user's profile Send private message
Bobby Nelson


From:
North Carolina, USA
Post  Posted 14 May 2019 11:40 pm
Reply with quote

You can pick up a SF twin for 6-8 hundred dollars, split the cabs for weight, and not destroy a classic Super. I like my JBL K-120s - great tone to the bone.
View user's profile Send private message Send e-mail
Bob Hoffnar


From:
Austin, Tx
Post  Posted 15 May 2019 5:03 am
Reply with quote

There is no such thing as “voiced for steel “. Please don’t screw up a great amp. The only problem with some amps is that steel pickups have much more output than guitar pickups (this is because they are bigger ) and sometimes will overload the input. This is easy to solve by plugging into the second input on old fender amps.
_________________
Bob
http://liminalsoundseries.com/
View user's profile Send private message Send e-mail
Bobby Nelson


From:
North Carolina, USA
Post  Posted 18 May 2019 11:20 pm
Reply with quote

Quote:
This is easy to solve by plugging into the second input on old fender amps.



This is what I had to do in my twin - works great.
View user's profile Send private message Send e-mail
Benjamin Davidson


From:
Connecticut, USA
Post  Posted 19 May 2019 4:08 am
Reply with quote

I wouldn't bother trying to voice the Super Reverb anything different than what is was from the factory. These Fenders sounded great in their day and are collectable for a reason. I run my PSG into the 2nd input of my Deluxe Reverb to tame some of the high output of the pickups.

Power at 45 watts isn't that big of an issue, when you consider that most gigs now a days are playing at a lower volume and/or mic'ing the cab.

You've mentioned that you are going away from the 4x10 cab (which if memory serves is a 2 Ohm load on the output transformer), that is the variable we should address. When you determine the speaker configuration that you want, you will need to replace the output transformer to match your intended speaker loading, if required.

The "Vibrato Off" modification I see most do, will have zero effect on output wattage and frequency sweep. D-Lab Electronics on YouTube did a great before and after video de-bunking that modification.
View user's profile Send private message
Steve Schmidt


From:
Ramsey, MN, USA
Post  Posted 19 May 2019 4:58 am
Reply with quote

I pulled my chassis out of my 66 super reverb and built a single 12" cabinet with a 12". I bought a replacement 4/8 ohm output transformer from classic tone. You could always put your original amp back together. The super reverb makes an excellent steel amp. I have since had Mike Skaggs build me his version. I like them both.
View user's profile Send private message Send e-mail
K Maul


From:
Mechanicville NY/Hobe Sound FL
Post  Posted 19 May 2019 6:21 am
Reply with quote

Buy a used Nashville 400 or 112. Cheaper than all that hacking and slashing on a classic Fender amp.
And faster.
_________________
Kevin Maul: Asher, Beard, Clinesmith, Evans, EXCEL, Fender, Fishman, Fluger, GFI, Gibson, Quilter, RAM, Redline, Rickenbacher, Sho~Bud, Supro, ZKing.
View user's profile Send private message Send e-mail Visit poster's website
Michael Deering


From:
Arizona, USA
Post  Posted 19 May 2019 7:10 am
Reply with quote

opps

Last edited by Michael Deering on 19 May 2019 7:20 am; edited 1 time in total
View user's profile Send private message Send e-mail
Michael Deering


From:
Arizona, USA
Post  Posted 19 May 2019 7:11 am
Reply with quote

Keep your eyes open for a old Fender steel amp with the 15" speaker. I picked 1 up this week in new condition for $150. You never know! WOW! Unplugged My 5watt champ amp and into my Rickenbacher and took off!
Another old Fender amp to look out for is the
1980's Fender 75 tube amp. Switchable between 15 or 75 watts, 15" Jensen speaker, clean and lead channel, push pull tone boosters, footswitch to go from clean to lead or reverb on and off. Reverb sounds fantastic. Last of the hand wired Fender amps.
View user's profile Send private message Send e-mail
